| Vehicle model number | SH-CX020T | Body size | 2300*1220*1880mm | Seat | 2People |
| Electrical system | |||||
| Battery Motor power | 12v80a | 48v3kw | |||
| 60v3kw | |||||
| 60v4kw | |||||
| 8v150ah | 48v3kw | ||||
| 48v4kw | |||||
| Charger machine | Fully automatic computer smart charger | Charging time | 8-10H | Charging input voltage | 220V/110V |
| Technical parameters | |||||
| Brake distance | ≤4 | Vehicle load | 600kg | Quality of the whole vehicle equipment | 450kg |
| Front and rear wheel distance | 870/980mm | Maximum climbing degree | 0.2 | Maximum driving speed | 28km/h |
| Wheelbase | 1640mm | Minimum turning radius | 4m | Minimum ground clearance | 140mm |
| Body system | |||||
| Seat | A row of seats(high rebound leather seats + with armrest) | Car body | PP Case Exquisite Pouch with Battery Storage Case + Straight Plate Plexiglass | ||
| Instrument | Instrument cluster | Mirror Mirrors | Manual type external rearview mirror | ||
| Light and signal | Combine headlights, turn signal, rear taillight, brake light,electric horn | Switch-off | Start switch, light switch, advance shift and other warp switch | ||
| Car Rame | Steel frame is phosphorysed by acid washing | The Steering Wheel | Polyurethane steering wheel | ||
| Chassis system | |||||
| Drive train | Unpolar FM system | Steering system | Automatic atically the gear rack direction machine | ||
| Front bridge and suspension | Plate spring suspension + cylinder hydraulic shock absorption | Rear bridge and suspension | Overall rear axle + high strength steel plate spring + cylinder hydraulic shock absorption | ||
| Brake system | Four-wheel hydraulic brake system + hand brake device | Tire | 205 / 50-10 (aluminum alloy hub) | ||
| Package dimensions | 2330*1150*900 | ||||
