| Vehicle model number | SH-CX040T |
| Body size | 3120*1200*1880mm |
| Seat | 4People |
| Battery and Motor power | 12v80a | 60v3kw |
| 60v4kw | ||
8v150ah | 48v3kw | |
| 48v4kw | ||
| 48v5kw | ||
| Charger machine | Fully automatic computer smart charger | |
| Charging time | 8-10H | |
| Charging input voltage | 220V/110V | |
| Brake distance | ≤4 |
| Front and rear wheel distance | 890/990mm |
| Wheelbase | 2390mm |
| Vehicle load | 600kg |
| Maximum climbing degree | 0.2 |
| Minimum turning radius | 4.5m |
| Quality of the whole vehicle equipment | 500kg |
| Maximum driving speed | 28km/h |
| Minimum ground clearance | 140mm |
| Seat | A row of seats(high rebound leather seats + with armrest) |
| Instrument | Instrument cluster |
| Light and signal | Combine headlights, turn signal, rear taillight, brake light,electric horn |
| Car Rame | Steel frame is phosphorysed by acid washing |
| Car body | PP Case Exquisite Pouch with Battery Storage Case + Straight Plate Plexiglass |
| Mirror Mirrors | Manual type external rearview mirror |
| Switch-off | Start switch, light switch, advance shift and other warp switch |
| The Steering Wheel | Polyurethane steering wheel |
| Tire | 205 / 50-10 (aluminum alloy hub) |
| Package dimensions | 3130*1150*900 |
